Thermal release tape, Thermal release double side tape

Double side thermal release tape

Thermal Release Double Side Tape, Transfer Tape

Model : SDF

Q'ty :

Sandwich type of thermal release tape :

♠ Double side with foaming adhesive, for any production process, as carrier or temporary fixing.

♠ Single side foaming adhesive, for any production process, as carrier or temporary fixing.

♠ Thermal release temperature: 85~260°C

Model	Material	Physical Property			Temp.
SDF30850-1R	PET Film Double side thermal release adhesive	Total thickness	130 ± 7	um	Release Temperature 85℃ , 3-5 min
		Before heating adhesion	0.1-0.4	kg/in
		After heating adhesion	0.015 ↓	kg/in
SDF90910	PET Film Double side thermal release adhesive	Total thickness	186 ± 10	um	Release Temperature 90℃ , 3-5 min
		Before heating adhesion	0.8 ↑	kg/in
		After heating adhesion	0.015 ↓	kg/in
SDFA90910	PET Film One side thermal release / the other side PSA	Total thickness	160 ± 9	um	Release Temperature 100℃ , 3-5 min
		Before heating adhesion	0.9 ↑	kg/in
		After heating adhesion	0.015↓	kg/in
		PSA adhesion	0.2 ↑	kg/in
SDF91210-2	PET Film Double side thermal release adhesive	Total thickness	180 ± 10	um	Release Temperature 120℃ , 3-5 min
		Before heating adhesion	1.0 ↑	um
		After heating adhesion	0.015↓	kg/in
SDF91510-2	PET Film Double side thermal release adhesive	Total thickness	190 ± 10	um	Release Temperature 150℃ , 3-5 min
		Before heating adhesion	0.9 ↑	um
		After heating adhesion	0.015 ↓	kg/in
SDF71938-2	PET Film Double side thermal release adhesive	Total thickness	144 ± 8	um	Release Temperature 190℃ , 3-5 min
		Before heating adhesion	0.5 ↑	kg/in
		After heating adhesion	0.015 ↓	kg/in
SDFA72038	PET Film One side thermal release / the other side PSA	Total thickness	96 ± 5	um	Release Temperature 210℃ , 3-5 min
		Before heating adhesion	0.3 ↑	kg/in
		After heating adhesion	0.015↓	kg/in
		PSA adhesion	0.3↑	kg/in

Transfer type of thermal release tape:

Model : UAS

Model : GT

Model : LE

Model : UET / UPT

Model : ETT / SAT

Model : SDK
